Description
A game changer for residential HVAC.
The Hylex™ unit is our first universal, inverter-driven heat pump that serves as a direct replacement for a traditional cooling-only or heat pump unitary outdoor unit. In other words, the game is about to change for residential HVAC.
-
AC Features
REUSE EXISTING REFRIGERANT PIPINGThe Hylex™ unit uses traditional unitary line sets where the liquid pipe does not require insulation and provides three suction pipe diameter options for even greater installation flexibility for replacement applications.
-
REUSE EXISTING CONTROLS WIRINGWhether the system is configured as a cooling-only or heat pump, only 2 wires are required between the indoor and outdoor sections. In addition, the Hylex™ unit is compatible with virtually any 24VAC thermostat and can use standard solid-core 18 AWG control wire from the outdoor unit to the indoor section and to the thermostat.
-
COMPACT SIZEThe Hylex™ unit has a smaller footprint compared to a traditional unitary (cube) unit, making it easier to move using a dolly, easier to get through gates and requires less space on the installer’s truck. In addition, its compact size makes it an ideal solution for new residential zero-lot-line properties.
Additional Information
 | Product Registration Required. Conditions Apply. |
 | The AHRI Certified® mark indicates Samsung’s participation in the AHRI Certification program. For verification of individual certified products, go to www.ahridirectory.org. |
 | Select models are ENERGY STAR® labeled. Proper sizing and installation of equipment is critical to achieve performance. Split system air conditioners and heat pumps (excluding ductless systems) must be matched with appropriate coil components to meet ENERGY STAR® criteria. Ask your contractor for details or visit www.energystar.gov. |
 |
-
- • Available in capacities ranging from 2 to 5 tons, offering flexibility for various residential needs; for the 3-ton unit, options include both single and double fan configurations.
- • Opt for the single fan setup for compact installations or choose the two-fan option to maximize efficiency.
- • Achieve impressive SEER ratings of up to 18.5 and HSPF ratings of up to 9.0, ensuring energy-efficient operation throughout the year.
- • Designed to seamlessly connect to any coil equipped with a TXV (certain conditions may apply), facilitating easy integration into existing systems.
- • Versatile compatibility allows for use with either a furnace or A-coil, enabling dual fuel applications¹ to optimize heating efficiency.
- • Configure the unit to operate as either a heat pump or cooling-only system, providing flexibility based on climate and preferences. • Compatible with a wide range of 24VAC thermostats, ensuring compatibility with existing home setups.
- • Features a full variable speed compressor with wide modulation, enhancing performance and providing precise temperature control.
- • Equipped with a base pan heater as standard, offering reliable operation even in cold weather conditions.
- • Operating range extends from -4°F (-20°C) to 125°F (51.7°C) for cooling and down to -13°F (-25°C) for heating.
- • Maintains 100% rated heating capacity even at low temperatures, ensuring consistent comfort regardless of outdoor condition
